CSE-250 Fall 2022 - Section B - Orderings, Priority Queues

Examples

$(B, 10)$ , $(D, 3)$ , $(E, 40)$
“A+”, “C”, “B-”
Taco Tuesday, Fish Friday, Meatless Monday
The Princess Bride, Crouching Tiger Hidden Dragon, Rob Roy
Aardvark, Baboon, Capybara, Donkey, Echidna, ...

Ordering

An ordering $(A, \leq)$ (an ordering over type $A$ ) is ...

A collection (set) of things of type $A$
A "relation" or comparator $\leq$ that relates two things

$5 \leq 30 \leq 999$: Numerical order
$(E, 40) \leq (B, 10) \leq (D, 3)$: Reverse-numerical order on the 2nd field
$C+ \leq B- \leq B \leq B+ \leq A- \leq A$: Letter grades
$AA \leq AM \leq BZ \leq CA \leq CD$: Compare 1st letter, if same compare 2nd, if same compare 3rd, ... ("Lexical Order")

Ordering Properties

Crouching Tiger Hidden Dragon $\leq$ Princess Bride: Carey Elwes and Mandy Patankin have amazing banter
Princess Bride $\leq$ Rob Roy: Rob Roy: Best climactic duel of all time
Rob Roy $\leq$ Crouching Tiger Hidden Dragon: A ton of amazingly technical fights

Ordering Properties

An ordering needs to be...

Reflexive: $x \leq x$
Antisymmetric: If $x \leq y$ and $y \leq x$ then $x = y$
Transitive: If $x \leq y$ and $y \leq z$ then $x \leq z$

Ordering Properties

Course 1 $\leq$ Course 2 iff Course 1 is a prereq of Course 2

CSE 115 $\leq$ CSE 116
CSE 116 $\leq$ CSE 250
CSE 115 $\leq$ CSE 191
CSE 191 $\leq$ CSE 250

Ordering Properties

Is this a valid ordering?

Yes!

(Partial order, as opposed to Total order)

(Partial)Ordering Properties

A partial ordering needs to be...

Reflexive: $x \leq x$
Antisymmetric: If $x \leq y$ and $y \leq x$ then $x = y$
Transitive: If $x \leq y$ and $y \leq z$ then $x \leq z$

(Total)Ordering Properties

A total ordering needs to be...

Reflexive: $x \leq x$
Antisymmetric: If $x \leq y$ and $y \leq x$ then $x = y$
Transitive: If $x \leq y$ and $y \leq z$ then $x \leq z$
Complete: Either $x \leq y$ or $y \leq x$ for any $x, y \in A$ .

Formally...

For a sort order $(A, \leq)$

Greatest: An element $x \in A$ s.t. there is no $y \in A$ , where $x \leq y$
Least: An element $x \in A$ s.t. there is no $y \in A$ , where $y \leq x$

A partial order may not have a unique greatest/least element

Formally...

$\leq$ can be described explicitly, by a set of tuples.

$\{\; (a, a), (a, b), (a, c), \ldots, (b, b), \ldots, (z, z) \;\}$

If $(x, y)$ is in the set, $x \leq y$

Formally...

$\leq$ can be described by a mathematical rule.

$\{\; (x, y) \;|\; x, y \in \mathbb Z, \exists a \in \mathbb Z_0^{+} : x + a = y \;\}$

$x \leq y$ iff $x, y$ are integers, and there is a non-negative integer $a$ s.t. $x + a = y$

Formally...

Multiple orderings can be defined for the same set.

RottenTomatoes vs Metacritic vs Box Office Gross.
"Best Movie" first vs "Worst Movie" first.
Rank by number of air ducts crawled through.

We use a subscripts to separate orderings (e.g., $\leq_1$ , $\leq_2$ , $\leq_3$ )

Formally...

We can transform orderings.

Reverse: If $x \leq_1 y$ , then define $y \leq_r x$

Lexical: Given $\leq_1, \leq_2, \leq_3, \ldots$

If $x \leq_1 y$ then $x \leq_\ell y$
If $x =_1 y$ and $x \leq_2 y$ then $x \leq_\ell y$
If $x =_2 y$ and $x \leq_3 y$ then $x \leq_\ell y$
....

Examples of Lexical Ordering

Names: First letter, then second, then third...
Movies: Average of reviews, then number of reviews...
Tuples: First field, then second field, then third...

Formally...

$\leq$ can be described an ordering over a key derived from the element.

$x \leq_{edge} y$ iff $weight(x) \leq weight(y)$

$x \leq_{student} y$ iff $name(x) \leq_{lex} name(y)$

We say that the weight (resp., name) is a key.

Topological Sort

A Topological Sort of a partial order $(A, \leq_1)$ is any total order $(A, \leq_2)$ over $A$ that "agrees" with $(A, \leq_1)$

For any two elements $x, y \in A$ :

If $x \leq_1 y$ then $x \leq_2 y$
If $y \leq_1 x$ then $y \leq_2 x$
Otherwise, either $x \leq_2 y$ or $y \leq_2 x$

Topological Sort

The following are all topological sorts over our partial order example:

CSE 115, CSE 116, CSE 191, CSE 241, CSE 250
CSE 241, CSE 115, CSE 116, CSE 191, CSE 250
CSE 115, CSE 191, CSE 116, CSE 250, CSE 241

(If the partial order is a schedule requirement, each topological sort is a possible schedule)

And now, for an ordering-based ADT...

Priority Queues

PriorityQueue[A <: Ordering]

enqueue(v: A): Unit: Insert a value $v$ into the priority queue.
dequeue: A: Remove the greatest element in the priority queue.
head: A: Peek at the greatest element in the priority queue.

enqueue(5)
enqueue(9)
enqueue(2)
enqueue(7)
head → 9
dequeue → 9
size → 3
head → 7
dequeue → 7
dequeue → 5
dequeue → 2
isEmpty → true

How do we store these items?

5, 9, 2, 7?

9, 7, 5, 2?

2, 5, 7, 9?

Two mentalities...

Lazy: Keep everything in a mess: "Selection Sort"
Proactive: Keep everything organized: "Insertion Sort"

Lazy Priority Queue

Base Data Structure: Linked List

enqueue(t:A): Append $t$ to the end of the linked list. $O(1)$
head/dequeue: Traverse the list to find the largest value. $O(n)$

Sort


  def pqueueSort[A](items: Seq[A], pqueue: PriorityQueue[A]): Seq[A] =
  {
    val out = new Array[A](items.size)
    for(item <- items){ pqueue.enqueue(item) }
    i = out.size - 1
    while(!pqueue.isEmpty) { buffer(i) = pqueue.dequeue; i-- }
    return out.toSeq
  }

Selection Sort

	Seq/Buffer	PQueue
Input	(7, 4, 8, 2, 5, 3, 9)	()
Step 1	(4, 8, 2, 5, 3, 9)	(7)
Step 2	(8, 2, 5, 3, 9)	(7, 4)
፧ ፧ ፧
Step N	[_, _, _, _, _, _, _]	(7, 4, 8, 2, 5, 3, 9)
Step N+1	[_, _, _, _, _, _, 9]	(7, 4, 8, 2, 5, 3)
Step N+2	[_, _, _, _, _, 8, 9]	(7, 4, 2, 5, 3)
Step N+3	[_, _, _, _, 7, 8, 9]	(4, 2, 5, 3)
Step N+4	[_, _, _, 5, 7, 8, 9]	(4, 2, 3)
Step N+5	[_, _, 4, 5, 7, 8, 9]	(2, 3)
Step N+6	[_, 3, 4, 5, 7, 8, 9]	(2)
Step 2N	[2, 3, 4, 5, 7, 8, 9]	()

Selection Sort


  def pqueueSort[A](items: Seq[A], pqueue: PriorityQueue[A]): Seq[A] =
  {
    val out = new Array[A](items.size)
    for(item <- items){ pqueue.enqueue(item) }
    i = out.size - 1
    while(!pqueue.isEmpty) { buffer(i) = pqueue.dequeue; i-- }
    return out.toSeq
  }

What's the complexity?

Proactive Priority Queue

Base Data Structure: Linked List

enqueue(t:A): Find $t$ 's position in reverse sorted order. $O(n)$
head/dequeue: Refer to the head item in the list. $O(1)$

Insertion Sort

	Seq/Buffer	PQueue
Input	(7, 4, 8, 2, 5, 3, 9)	()
Step 1	(4, 8, 2, 5, 3, 9)	(7)
Step 2	(8, 2, 5, 3, 9)	(7, 4)
Step 3	(2, 5, 3, 9)	(8, 7, 4)
Step 4	(5, 3, 9)	(8, 7, 4, 2)
Step 5	(3, 9)	(8, 7, 5, 4, 2)
Step 6	(9)	(8, 7, 5, 4, 3, 2)
Step N	[_, _, _, _, _, _, _]	(9, 8, 7, 5, 4, 3, 2)
Step N+1	[_, _, _, _, _, _, 9]	(8, 7, 5, 4, 3, 2)
፧ ፧ ፧
Step 2N	[2, 3, 4, 5, 7, 8, 9]	()

Insertion Sort


  def pqueueSort[A](items: Seq[A], pqueue: PriorityQueue[A]): Seq[A] =
  {
    val out = new Array[A](items.size)
    for(item <- items){ pqueue.enqueue(item) }
    i = out.size - 1
    while(!pqueue.isEmpty) { buffer(i) = pqueue.dequeue; i-- }
    return out.toSeq
  }

What's the complexity?

Priority Queues

Operation	Lazy	Proactive
enqueue	$O(1)$	$O(n)$
dequeue	$O(n)$	$O(1)$
head	$O(n)$	$O(1)$

Can we do better?

Orderings, Priority Queues

CSE-250 Fall 2022 - Section B

Textbook: Ch. 13.1
