CSE-250 Fall 2022 - Section B - Average Runtime, Stacks, Queues

Oct 3, 2022

A stack of objects on top of one another.

- Push
- Put a new object on top of the stack
- Pop
- Remove the object on top of the stack
- Top
- Peek at what's on top of the stack

Outside of the US, "queueing" is lining up.

- Enqueue
- Put a new object at the end of the queue
- Dequeue
- Remove the next object in the queue
- Head
- Peek at the next object in the queue

**Thought question:** How could you use an array to build a queue?

- Enqueue
- Append
- Dequeue
- Remove(0)

What's the complexity?

- Enqueue
- Insert(0)
- Dequeue
- Remove(last)

What's the complexity?

Can we avoid having to move all of the

elements forward or backward a spot?

_

_

_

_

Active Array = [start, end)

- Enqueue
- Resize buffer if needed
- Add new element at buffer[end]
- Advance end pointer (wrap around to front)
- Dequeue
- Remove element at buffer[start]
- Advance start pointer (wrap around to front)

What's the complexity?

- Stack: Checking for Balanced Parenthesis/Braces
- Queue: Scheduling Packets for Delivery
- Both: Searching Mazes

What does it mean for parenthesis/braces to be balanced?

- Every opening symbol is matched by a closing symbol
- No nesting overlaps (e.g.,
`{(})`is not ok).

{()({})} |
{()) |
()) |

✅ | ❌ | ❌ |

**Idea: ** Count the number of unmatched open parens, braces.

Increment counter on `(`, decrement on `)`

**Problem: ** allows `{(})`

**Idea: ** Track nesting on a stack!

On `(` or `{`, push the symbol on the stack.

On `)` or `}`, pop the stack and check the popped symbol.

- Router: 1gb/s internal network, 100mb/s external
- 1gb/s sent to router, but only 100mb/s can leave.
- How do packets get delivered?

- Queues
- Enqueue data packets in the order they are received.
- When outgoing bandwidth available, dequeue and send.

- Avoiding Queueing Delays
- Limit size of queue; Packets that don't fit are dropped

**TCP:** blocked packets are retried
**UDP:** application deals with dropped packets.

**O**is the start,**X**is the objective- There may be multiple paths
- Generally, we want the shortest

**Approach 1:**Take the first available route in one direction- Right, Down, Left, or Up
- Down, Right, Up, Left

**O**is the start,**X**is the objective- There may be multiple paths
- Generally, we want the shortest

**Approach 1:**Take the first available route in one direction- Right, Down, Left, or Up
- Down, Right, Up, Left

How do you know which one is best?

Other problems with this algorithm?

Priority order doesn't guarantee exploring the entire maze

**Inputs:**

- The map: An $n\times m$ grid of filled/empty squares.
- The
**O**is at position $start$ - The
**X**is at position $dest$

**Goal: **

How do we define $steps$?

$$steps(\texttt{pos},\texttt{dest}) = \begin{cases}
0 & \textbf{if } \texttt{pos} = \texttt{dest}\\
\end{cases}$$

$$steps(\texttt{pos},\texttt{dest}) = \begin{cases}
0 & \textbf{if } \texttt{pos} = \texttt{dest}\\
\infty & \textbf{if } is\_filled(\texttt{pos})\\
\end{cases}$$

$$steps(\texttt{pos},\texttt{dest}) = \begin{cases}
0 & \textbf{if } \texttt{pos} = \texttt{dest}\\
\infty & \textbf{if } is\_filled(\texttt{pos})\\
1 + min\_adjacent(\texttt{pos}, \texttt{dest}) & \textbf{otherwise}
\end{cases}$$

where...

$min\_adjacent(\texttt{pos}, \texttt{dest}) = $ $$\min\begin{cases} steps(moveRight(\texttt{pos}), \texttt{dest})\\ steps(moveDown(\texttt{pos}), \texttt{dest})\\ steps(moveLeft(\texttt{pos}), \texttt{dest})\\ steps(moveUp(\texttt{pos}), \texttt{dest})\\ \end{cases}$$

**if**`pos == dest`**then**`return 0`**elif**`is_filled(pos)`**then**`return ∞`**else**`return 1 +`min of- $steps(moveRight(\texttt{pos}, \texttt{dest}))$
- $steps(moveDown(\texttt{pos}, \texttt{dest}))$
- $steps(moveLeft(\texttt{pos}, \texttt{dest}))$
- $steps(moveUp(\texttt{pos}, \texttt{dest}))$

**Problem: ** Infinite loop!

**Insight: ** A path with a loop in it can't

be shorter than one without the loop.

Mark nodes as visited

**if**`pos == dest`**then**`return 0`**elif**`pos`marked visited**then**`return ∞`**elif**`is_filled(pos)`**then**`return ∞`**else**- Mark
`pos`as visited `return 1 +`min of all 4 steps

- Mark

**Problem: ** The first time you visit a node,

it may be via a longer path!

Unmark nodes as you leave them

**if**`pos == dest`**then**`return 0`**elif**`pos`marked visited**then**`return ∞`**elif**`is_filled(pos)`**then**`return ∞`**else**- Mark
`pos`as visited `stepCount = 1 +`min of all 4 steps- Unmark
`pos`as visited `return stepCount`

- Mark

**Inputs:**

- The map: An $n\times m$ grid of filled/empty squares.
- The
**O**is at position $start$ - The
**X**is at position $dest$

**Goal: **

What path did we take?

Idea:

Follow the nodes marked visited**if**`pos == dest`**then**`return visited.copy()`**elif**`pos`∈`visited``return no_path`**elif**`is_filled(pos)`**then**`return no_path`**else**`visited.append(pos)``bestPath =`min of all 4 one-step paths`visited.removeLast()``return bestPath`

**if**`pos == dest`**then**`return visited.copy()`**elif**`pos`∈`visited``return no_path`**elif**`is_filled(pos)`**then**`return no_path`**else**`visited.push(pos)``bestPath =`min of all 4 one-step paths`visited.pop()``return bestPath`

**Thought question:** Can you solve a maze

with a **queue** instead?
